| Diámetro Esfera | 1.1/2" (38mm) |
| Cuerpo | Acero pintado color negro |
| Conexión | 1/8" NPT Bronce |
| Visor | Policarbonato |
| Glicerina | No |
| Temperatura Ambiente | -40°C a 65°C |
| Temperatura Fluido | -40°C a 65°C |
| Aplicación | Aire, agua, aceite y fluidos compatibles con conexión |
| Codigo | BAR | PSI |
| M063A-001 | 0 - 1 | 0 - 15 |
| M063A-002 | 0 - 2 | 0 - 30 |
| M063A-004 | 0 - 4 | 0 - 60 |
| M063A-007 | 0 - 7 | 0 - 100 |
| M063A-010 | 0 - 10 | 0 - 150 |
| M063A-014 | 0 - 14 | 0 - 200 |
| M063A-020 | 0 - 20 | 0 - 300 |
| M063A-025 | 0 - 25 | 0 - 375 |
| M063A-035 | 0 - 35 | 0 - 500 |
| M063A-040 | 0 - 40 | 0 - 600 |
| M063A-070 | 0 - 70 | 0 - 1,000 |
| M063A-100 | 0 - 100 | 0 - 1,500 |
| M063A-140 | 0 - 140 | 0 - 2,000 |
| M063A-175 | 0 - 175 | 0 - 2,500 |
| M063A-250 | 0 - 250 | 0 - 3,500 |
| M063A-300 | 0 - 300 | 0 - 4,500 |
| M063A-350 | 0 - 350 | 0 - 5,000 |
| M063A-400 | 0 - 400 | 0 - 6,000 |
| M063A-700 | 0 - 700 | 0 - 10,000 |
| Codigo | BAR | PSI |
| M063B-001 | 0 - 1 | 0 - 15 |
| M063B-002 | 0 - 2 | 0 - 30 |
| M063B-004 | 0 - 4 | 0 - 60 |
| M063B-007 | 0 - 7 | 0 - 100 |
| M063B-010 | 0 - 10 | 0 - 150 |
| M063B-014 | 0 - 14 | 0 - 200 |
| M063B-020 | 0 - 20 | 0 - 300 |
| M063B-025 | 0 - 25 | 0 - 375 |
| M063B-03 | 0 - 35 | 0 - 500 |
| M063B-040 | 0 - 40 | 0 - 600 |
| M063B-070 | 0 - 70 | 0 - 1,000 |
| M063B-100 | 0 - 100 | 0 - 1,500 |
| M063B-140 | 0 - 140 | 0 - 2,000 |
| M063B-175 | 0 - 175 | 0 - 2,500 |
| M063B-250 | 0 - 250 | 0 - 3,500 |
| M063B-300 | 0 - 300 | 0 - 4,500 |
| M063B-350 | 0 - 350 | 0 - 5,000 |
| M063B-400 | 0 - 400 | 0 - 6,000 |
| M063B-700 | 0 - 700 | 0 - 10,000 |
